22KW Electric High Pressure Washer

FEATURES AND BENEFITS

1. Fully enclosed box, waterproof, dust-proof, and explosion-proof;

2. Uses fully automatic backwash filter to ensure entry into the equipment The water is free of impurities and improves service life.

3. The 3M CCC GB power cord andthe 10 meter high-pressure water outlet pipe make it easy to clean large areas without constantly relocating the machine.

Quality assurance of 22KW Electric High Pressure Washer

① Electric Current protection range from 15A to 18A

② Power protection range from 7.5Kw to 8.5Kw

③ Voltage protection:  220V single phase 170V to 245V ,   380V three phase 360V to 440V

④ Electric leakage protection at 30mAh

⑤ Open-phase protection for 380V three phase motor

⑥ Over heating protection for the motor at 120 degree

⑦ Error nozzle connect will not raise the electric current and voltage increase, motor will not broken, the pump is with the function of automatic pressure leakage.

⑧ New models for pump in 3000Hrs testing without the situation of oil leakage and water leakage

SPECIFICATIONS

Technical data

ACCESSORIES

1. JNK 500 kgs high pressure water gun with connector M22*1.5 inner diameter 16mm

2. 10 meter double high pressure water outlet pipe with connectorM22*1.5 inner diameter 16mm(304)

3. CCC GB power cord 4M*10mm²

1. 3 meters water return piper of material of 3 layers rubber, 2 lines and 1 steel wire

4. 3 Meters inlet water pipe of material of 3 layers rubber, 3lines and 1 steel wire, with 304 double stainless steel filter mesh

5. Nozzles, stainless steel 304 clips, gaskets

6. Stainless steel filter 304  stainless steel with 3 layers filter mesh

APPLICATION AREAS

1. Vehicle cleaning

2. Cleaning outdoor spaces

3. Workshop cleaning

4. Service station cleaning

5. Swimming pool cleaning

6. Fleet washing

7. Steam washing

8. Rail equipment cleaning

9. Heavy equipment cleaning

10. Building cleaning

11. Ware house cleaning

12. Acid&chemical washing

13. Wash station rentals

14. Club root washing

15. Disinfection&sanitizing service

16. High pressure cleaning

17. High pressure rusty removing

18. Pigsty cleaning

19. Poultry cleaning

20. Kitchen cleaning
